KCB gear pumps

item no.:
KCB18.3/55/83.3/200/300/483.3/633/960/1600/5400
lead time:
Customer Date
product orgin:
china saiken pumps
shipping port:
Tianjin China
payment:
L/C Or T/T
color:
Customer Color

contact now

description

KCB gear pump

KCB gear pump is suitable for conveying lubricating oil or other liquids with similar properties to lubricating oil without solid particles and fibers, whose temperature is not higher than 300, viscosity is It can be used as a transmission and booster pump in the oil transportation system......

KCB gear pump performance range:

MODEL: KCB 18.3,KCB 33.3,KCB 55,KCB83.3,KCB 135,KCB 200,KCB 300,KCB 483.3,KCB 633, KCB 960,KCB 1200,KCB 1600,KCB 2500,KCB 3800,KCB 5400,KCB 9600.

Pressure range:≤1.45MPa

Flow range: ≤580m³/h

Temperature range: ≤300℃

The viscosity range is: 5 ~ 1500mm2/s, and the speed can be reduced to 50000mm2/s.

Structural features of KCB gear pumps:

This series of gear pumps are mainly composed of gear, shaft, pump body, valve, shaft end seal (special requirements, optional magnetic drive, zero leakage structure). The gear has high hardness and strength through heat treatment and is installed with the shaft in the commutable shaft sleeve. The lubrication of all parts in the pump is automatically achieved by using the output medium when the pump works.

The pump has a reasonable design of oil drain and return groove, is the gear in the work of the torque bearing force is small, so the bearing load is small, wear is small, pump efficiency is high.

The pump is equipped with a safety valve as overload protection. The full return pressure of the safety valve is 1.5 times the rated discharge pressure of the pump. It can also be adjusted according to actual needs within the allowable discharge pressure range. But note that this safety valve can not be used as a pressure reducing valve for a long time.

Viewed from the extension of the spindle to the pump, it rotates clockwise.

KCB series gear pump uses:

It is suitable for transporting lubricating oil without solid particles and fibers, temperature not higher than 300 C, viscosity 5×10 - 6 1.5×10 - 3 m2 / s (5 - 1500 cSt) or other liquids similar to lubricating oil.

Reduce the speed of the pump, the viscosity of the conveying medium can reach 50000mm2/s.

KCB gear pump application area:

It can be used as transmission and booster pump in oil transportation system.

It can be used as fuel pump for conveying, pressurizing and spraying in the fuel system.

It can be used as lubricating oil pump in all industrial fields.

KCB Gear Pump Model Parameters:

Model	Capacity Q		Speed r/min	Exhaust Pressure Mpa	(NPSH)r m	Efficiency η %	Motor
	m3/h	L/min					Power kw	Model
KCB-18.3	1.1	18.3	1400	1.45	5	44	1.5	Y90L-4
2CY-1.1/1.45
KCB-33.3	2	33.3	1420	1.45	5	44	2.2	Y100L1-4
2CY-2/1.45
KCB-55	3.3	55	1400	0.33	7	41	1.5	Y90L-4
2CY-3.3/0.33
KCB-83.3	5	83.3	1420	0.33	7	43	2.2	Y100L1-4
2CY-5/0.33
KCB-135	8	135	940	0.33	5	46	2.2	Y112M-6
2CY-8/0.33
KCB-200	12	200	1440	0.33	5	46	4	Y112M-4
2CY-12/0.33
KCB-300	18	300	960	0.36	5	42	5.5	Y132M2-6
2CY-18/0.36
KCB-483.3	29	483.3	1440	0.36	5.5	42	11	Y160M-4
2CY-29/0.36
KCB-633	38	633	970	0.28	6	43	11	Y160L-6
2CY-38/0.28
KCB-960	58	960	1470	0.28	6.5	43	18.5	Y180M-4
2CY-58/0.28
KCB-1200	72	1200	740	0.6	7	43	37	Y280S-8
KCB-1600	95	1600	980				45	Y280S-6
KCB-1800	112	1800	740	0.6	7.5	43	55	Y315S-8
KCB-2500	150	2500	985				75	Y315S-6
KCB-2850	170	2850	740	0.6	8	44	90	Y315L1-8
KCB-3800	230	3800	989				110	Y315L1-6
KCB-4100	245	4100	743	0.6	8	44	132	Y355M1-8
KCB-5400	325	5400	989				160	Y355M1-6
KCB-5600	330	5600	744	0.6	8	44	160	Y355M2-8
KCB-7600	460	7600	989				200	Y355M3-6
KCB-7000	420	7000	744	0.6	8	44	185	Y355L1-8
KCB-9600	570	9600	989				250	Y355L2-6
