CFRETFE PP GFRPP Magnetic Drive Sealless Pump

  • item no.:

    Magnetic Drive Sealless Pump
  • lead time:

    Customer Date
  • product orgin:

  • shipping port:

    Tianjin China
  • payment:

    L/C Or T/T
  • color:

    Customer Color
  • description
Magnetic Drive Sealless Pump body made of CFRETFE/PP/GFRPP

1. Outstanding Acid / Alkaline Resisting Capability
The material of pump body has four kinds to choose from, including PP(Polypropylene), GFRPP(Glass Fiber Filled Polypropylene), PVDF(Natural PVDF), CFRETFE(Carbon Fiber Filled ETFE). Correct choice of pump body material depends on acid / alkaline density of solution. To satisfied the market demand, saiken was the pioneer to provide PP pump material for enhancing the capability of acid resistance. The PP / GFRPP material can resist temperature up to 75℃. The PVDF material can resist temperature up to 90℃. The CFRETFE material can resist temperature up to100℃. In application almost all solutions can be transferred with safety.
Flow rate up to 350LPM, Max. head 35 m, Max power 5hp

2. Corrosion Resisting
The major parts of the pump feature outstanding corrosion-resist capability. For example the pump spindle can be made from ceramic and SIC. The ceramic spindle is generally applied for low corrosion liquid. The SIC spindle is excellent for high corrosion liquid.

3. Unique design of Bearing for dry running endure
Due to the unique design of Bearing, while the pump operating normally, the fluid circulated cooling with impeller, spindle and magnet capsule. Although the pump dry-running, the temperature cannot be get higher quickly to avoid pump be damaged seriously.

4. Easy to Assemble
The internal parts of a magnetic drive sealless pump are fully standard for easy assembling  completely constructed with high performance. Parts replacement is easy to made without need to of any specially tool. It features convenient maintenance, dismantling and inspection for time saving service.

5. Maximum Durability
The (0.37Kw~3.75Kw) series pump employs extra powerful permanent magnet featuring
outstanding performance and coupling capability.

6. Versatile Applications
The magnetic drive sealless pump is ideal for low capacity with high head or high capacity
with low head applications. It is widely applied in various industrial process. Such as PCB process, chemical industry, circulated filtering, etching, plating, surface treatment, polluted water treatment, etc. these pumps assure outstanding performance and maximum durability.

Request a free quote
