UHMWPE Plastic Chemical Pump

item no.:
PPPEUHMW-PEPVDFFEPPFA Plastic Chemical Pump
lead time:
Customer Date
product orgin:
shipping port:
Tianjin China
payment:
L/C Or T/T
color:
Customer Color

contact now

description

Application:

Chemically aggressive, even contaminated, media throughout the whole range of chemical processing technology, surface coating technology, environ-mental engineering and other areas of industry.

Performance data

Pump capacity: up to 1200 m³/h

Total differential head: up to 100 m

Operating temperature [t]: -20°C up to +110 °C

Operating pressure [p]: up to 10 bar

Diameter of discharge nozzle: DN 25 up to DN 250

Drive rating [P]: up to 200 kW

1.Chlor-Alkali Electrolysis

2.Sulphuric acid

3.Steel and Stainless steel pickles

4.Titanium dioxide

5.Phosphoric acid

6.Sea water

7.Waste incineration (flue gas cleaning)

8.Scrubber

9.Waste water

10.Hydrochlorid acid

Type: Horizontal, single-stage

Construction: Back-pull-out design according to ISO 2858

Impeller:Closed or semi-open

Sealings: Single type or double type

Bearing lubrication: Grease

Installation versions: Base frame welded or cast iron base plate

Ambient temperature: -20deg.c to 60deg.c

Solid content limit value: approx. 5 %

Materials: PP,PE,UHMW-PE,PVDF,FEP,PFA

Operation temp: Up to 110 deg.c
