3G Screw Pump For Lubricating Oil

item no.:
3G42*6/3G85*2
lead time:
Customer Date
product orgin:
Botou Saiken Pumps Co.Ltd
shipping port:
Tianjin China
payment:
L/C Or T/T
color:
Customer Color

contact now

description

3G Screw Pump Specification:

Temperature:≤150 degrees

Viscosity:5-760 cst

Pressure range:0.6-2.5 Mpa

Flow rate range:0.6-123m³/h

Medium:

1. Lubricating liquid: such as mechanical oil, lubricating oil, heavy oil, residuum

2. Low lubricity liquid: such as light diesel oil, heavy diesel oil, and waxy oil

3. Viscous liquids: such as various synthetic rubber fluids and synthetic rubber fluids, emulsions.
3G Screw Pump Manufacturer in china,Exporter & supplier of 3G/3GR/3GW/3GN Three Screw Pump.

For instance:

Model

Pressure

(Mpa)

Capacity

Speed

(r/min)

NPSHR

(m)

Efficiency

(%)

Motor

m³/h

L/min

Power(kw)

Model

42*4-46

1.0

2.5

4.8

4.2

1450

5.5

Y112M-4

Y132S1-4

1.0

2.5

10.5

175

166

2900

5.5

Y132S1-2

Y160M2-2

Screw pump according to the use of classification is divided into 5 Series

Model	Usage	Performance range
Model	Usage	Capacity(m³/h)	Pressure(Mpa)
3G	Transfer lubricating oil ,viscosity 3-20oE, temperature≤80 degrees	0.6-570	2.5
3Gr	Transfer heavy fuel oil ,viscosity 3-50oE temperature≤120 degrees	0.6-570	2.5
3Gr	Transfer light fuel oil ,viscosity 2-5oE temperature≤120 degrees	0.6-570	1.6
3GW	Transfer high temperature feul heated oil, temperature≤150 degrees	0.6-.363	2.5
3GN	Transfer high viscosity oil 100oE , temperature≤80 degrees	0.6-636	2.5
