Pneumatic-diaphragm-pump-for-ink-printing

Pneumatic diaphragm pump for ink printing

item no.:
lead time:
Customer Date
product orgin:
shipping port:
Tianjin China
payment:
L/C Or T/T
color:
Customer Color

contact now

description

Pneumatic diaphragm pump for ink printing

Pneumatic Diaphragm Pump Application and Advantage:

Pneumatic diaphragm pumps are operated with compressed air . diaphragm pumps is suitable for pumping fluids with particles, and various liquids, which are highly viscous, volatile, corrosive or toxic, as well as colloids. The pump body is made of aluminum alloys, cast iron or stainless steel. The diaphragm is made of high quality rubber such as Nitrile rubber, chloronorgutta rubber, fluoroine rubber. The diaphragm pumps are widely used in the petroleum chemical, electronic, ceramic, food and textile industries

Model	Inlet/outlet Dia	Max. Flow		Head	Max. Suction stroke	Max. Particle Dia.	Max. Air Supply Pressure	Max.Air Consumption
Model	inch	m3/h	L/min	m	m	mm	kg/cm2	m3/min
SKQ-06/10	1/4 or 3/8	1.62	27	0-70	6.4	1.6	7	0.14
SKQ-15/20	1/2 or 3/4	3.42	57	0-84	7.6	2.5	8.4	0.56
SKQ-25	1	9.42	157	0-84	8	4	8.4	1.12
SKQ-40	1.5	21.48	358	0-84	8	5	8.4	2.24
SKQ-50	2	35.22	587	0-84	8	6	8.4	2.8
SKQ-80	3	63.6	1060	0-84	8	9.4	8.4	9.8

tags :

Previous：Pneumatic diaphragm pump for ink coating transfer
Next：Pneumatic diaphragm pump for wastewater transfer
