KCB-18.3 33.3 55 83.3 Gear Pump Manufacturer

  • item no.:

    KCB-18.3 33.3 55 83.3
  • lead time:

    Customer Date
  • product orgin:

    CHINA SAIKEN PUMPS
  • shipping port:

    Tianjin China
  • payment:

    L/C Or T/T
  • color:

    Customer Color
  • description
KCB-18.3 33.3 55 83.3 Gear Pump Manufacturer by china saiken pumps
KCB 18.3 gear pump flow is 18.3L/min;  discharge pressure:1.45Mpa, Inlet/Outlet:3/4″;  Motor:1.5KW-1420RPM; Material: cast iron, stainless steel
KCB 33.3 gear pump flow is 33.3L/min;  discharge pressure:1.45Mpa, Inlet/Outlet:3/4″;  Motor:2.2KW-1420RPM; Material: cast iron, stainless steel
KCB 55 gear pump flow is 55L/min;  discharge pressure:0.33Mpa, Inlet/Outlet:1″;  Motor:1.5KW-1420RPM; Material: cast iron, stainless steel
KCB 83.3 gear pump flow is 83.3L/min;  discharge pressure:0.33Mpa, Inlet/Outlet:1.5″;  Motor:2.2KW-1420RPM; Material: cast iron, stainless steel

The KCB gear pump is an external gear positive displacement pump,made of cast iron or stainless steel,Flow:18L~9600l/min,used to transfer heavy oil, fuel, engine oil and similar liquids without solids.
shaft seal: mechanical seal and gland packing.
Model:KCB-55 KCB-83.3 KCB-135 KCB-200 KCB-300 KCB-483.3 KCB-633 KCB-960 KCB-1600 KCB-1800 KCB-2500 KCB-3800 KCB-5400 KCB-7600 KCB-9600.
KCB Electric Oil Transfer Gear Pump is designed for pumping light fuel oils such as diesel, kerosene, and biodiesel. It is also possible to pump vegetable oil, motor oil, and even glycerol.
It is helical gear pump, and built-in by-pass valve. For pumping clean viscous liquids, not containing abrasive or solid particles.
They can run dry for only intermediate amounts of time, allowing for the use of a suction hose for collecting fluids from a tank. They should not be run dry for an extended period of time as oil is required to lubricate the pump head.
Application:
 In the oil system can be used for transmission, booster pump;
 In the fuel oil system can be used as a transport, pressure, jet fuel pump
 In the hydraulic drive system can be used to provide hydraulic power of hydraulic pump;
 In all industrial fields, all can be used as lubricating oil pump




KCB Gear Pump Model Parameters:


Model Capacity Q Speed
r/min
Exhaust
Pressure
Mpa
(NPSH)r
m
Efficiency
η %
Motor
m3/h L/min Power
kw
Model
KCB-18.3 1.1 18.3 1400 1.45 5 44 1.5 Y90L-4
2CY-1.1/1.45
KCB-33.3 2 33.3 1420 1.45 5 44 2.2 Y100L1-4
2CY-2/1.45
KCB-55 3.3 55 1400 0.33 7 41 1.5 Y90L-4
2CY-3.3/0.33
KCB-83.3 5 83.3 1420 0.33 7 43 2.2 Y100L1-4
2CY-5/0.33
KCB-135 8 135 940 0.33 5 46 2.2 Y112M-6
2CY-8/0.33
KCB-200 12 200 1440 0.33 5 46 4 Y112M-4
2CY-12/0.33
KCB-300 18 300 960 0.36 5 42 5.5 Y132M2-6
2CY-18/0.36
KCB-483.3 29 483.3 1440 0.36 5.5 42 11 Y160M-4
2CY-29/0.36
KCB-633 38 633 970 0.28 6 43 11 Y160L-6
2CY-38/0.28
KCB-960 58 960 1470 0.28 6.5 43 18.5 Y180M-4
2CY-58/0.28
KCB-1200 72 1200 740 0.6 7 43 37 Y280S-8
KCB-1600 95 1600 980 45 Y280S-6
KCB-1800 112 1800 740 0.6 7.5 43 55 Y315S-8
KCB-2500 150 2500 985 75 Y315S-6
KCB-2850 170 2850 740 0.6 8 44 90 Y315L1-8
KCB-3800 230 3800 989 110 Y315L1-6
KCB-4100 245 4100 743 0.6 8 44 132 Y355M1-8
KCB-5400 325 5400 989 160 Y355M1-6
KCB-5600 330 5600 744 0.6 8 44 160 Y355M2-8
KCB-7600 460 7600 989 200 Y355M3-6
KCB-7000 420 7000 744 0.6 8 44 185 Y355L1-8
KCB-9600 570 9600 989 250 Y355L2-6
