5 Inch 125mm Aodd Pump Air Operated

  • item no.:

    SK-125
  • lead time:

    Customer Date
  • product orgin:

    CHINA SAIKEN PUMPS
  • shipping port:

    Tianjin China
  • payment:

    L/C Or T/T
  • color:

    Customer Color
  • description
5 Inch 125mm Aodd Pump Manufacturer

Aodd Pumps Made of Cast steel,Aluminum,PP (polypropylene), Stainless steel (SS304, SS 316, SS 316L), PVDF,Teflon.

AODD pumps also called air operated diaphragm pumps, are positive displacement pumps driven and powered by compressed air rather than an electric motor. The AODD pump design means that it can cope with pretty much any fluid from water to viscous slurries to 90% solids including large, shear sensitive particles without degrading them. Air operated double diaphragm pumps are able to benefit from variable flow or pressures just by adjusting the air power supply.

5 Inch 125mm Aodd Pump Air Operated  Specifications:

Model SK-125
Max.Flow                                                       275GPM (1041LPM)
Max.Working Pressure 120psi (0.84Mpa, 8.4bar)
Fluid Inlet Size                                               5 inch / 125 mm
Fluid Outlet Size 5 inch / 125 mm
Air Inlet Size                                                  3/4 inch
Max.Suction Height(dry suction)                  25ft (7.6M)
Max.Permitted Grain                                     3/8 inch (9.4mm)
Max.Air Consumption                                   82.6 scfm
Every Reciprocating Flow                            2.0 gal (7.6L)
Max.Reciprocating Speed 135 cpm
