Vertical acid and alkali chemical pump peculiarity


Vertical acid and alkali pump chemical pump can be divided into acid and alkali tank vertical pump and acid and alkali tank outside the vertical pump, according to the material can be divided into PP vertical pump, PVDF vertical pump, according to the use can be divided into desulfurization Tower vertical pump and exhaust tower spray pump. It is suitable for conveying a certain concentration of strong acid, alkali, salt, strong oxidant and other corrosive media, suitable for coating pretreatment, PP spray tower, electrophoresis cycle, etc., using dry liquid seal to prevent motor and bearing from being corroded by chemical gas, extend the service life of motor and pump.
1, can be used with the filter, transport a variety of chemical liquid, can be connected with the chemical liquid filter, suitable for a variety of chemical plating liquid circulation transport for temperature resistance or containing crystallization of chemical liquid, according to the different chemistry, the choice of material is also different.
2, can be used for the circulation of PC plate etching solution. Slot type easy installation, high pressure resistance, no leakage and easy maintenance. Can be customized according to the depth of the customer tank 700-1500mm. All the liquid parts of the pump are made of corrosion-resistant FRPP, CFRPP, PVDF material, the specific choice depends on the chemical liquid.
3. Transport of wastewater treatment equipment. Dry liquid seal design, anti-leakage and anti-acid gas corrosion effect is strong, when the pressure in the pump rises, block the overflow potion, will not produce stopping liquid backflow leakage, damage the pump.
4, can be used for washing washing tower, vertical pump a variety of caliber, a variety of power, according to the site tailored. Mold opening, testing equipment is complete.
5, can be used as a heat exchange cycle and with the filter filter operation. The embedded structure of the new integrated impeller greatly strengthens the strength of the impeller, also prolongs the service life, can resist high temperature and high pressure, and is not easy to damage.
6. Various liquid circulation transportation operations in the chemical mixing tank or filter tank, using corrosion-resistant FRPP, CFRPP, PVDF material, can transport acid and alkali and corrosive media.

Applications of vertical corrosion resistant pumps
1, suitable for sewage, waste gas, electroplating, coating, circuit board, chemical plant, photovoltaic, diamond wire, pharmaceutical, printing and dyeing, semiconductor, cleaning equipment and other fields.
2, suitable for water, seawater and chemical medium liquid transport with acid and alkalinity.
3, mostly used in pickling, painting, circuit board etching and exhaust gas spraying and other processes.
Vertical corrosion resistant pump easily handle sulfuric acid, hydrochloric acid, nitric acid, chromic acid, hydrofluoric acid, phosphoric acid, sodium hypochlorite and other acid and base liquids; Widely used in electroplating, coating, surface treatment, waste gas treatment and other fields.
